SPECIFICHE TECNICHE
Print method Thermal Transfer / Direct Thermal
Resolution 203 dpi (8 dot/mm) / 300dpi (12 dot/mm) / 600dpi (24 dot/mm)
Print speed Up to 16 ips (406 mm/s) / Up to 12 ips (305 mm/s) / Up to 8 ips (203 mm/s)
Print width 4.09” (104mm) / 4.09” (104mm, up to 105.7mm) / 4.09” (104mm, up to 105.6mm)
Print length Min. 0.12” (3 mm)** Max. 279.53” (7100 mm) / Min. 0.12” (3 mm)** Max. 125.98” (3200 mm) / Min. 0.12” (3 mm)**Max. 31.50” (800 mm)
Processor 32 Bit RISC CPU
Memory 256MB Flash ; 256MB SDRAM 16GB for display
Interfaces • USB 2.0 (Type B) • Serial port (RS-232)
• Ethernet 10/100 Mbps (IEEE 802.1X ‒ TBD)
• USB Host * 3(Type A) 2 ports at the front panel, 1 port at the rear panel
Ribbon • Types: Wax, wax/resin, resin
• Length: Max. 1476’ (450 m)
• Width: Min. 1.18” (30 mm) ‒ Max. 4.33” (110 mm)
• Ribbon roll diameter: 3” (76.2 mm)
• Core diameter: 1” (25.4 mm)
Control Panel • Backlight 5” touch screen LCD supports on-board videos
• 1 Power on/off button with blue color LED
